Dahua Multi-language IPC-HDW2439T-AS-LED-S2 4MP IP67 PoE Full-color IR 30M CCTV Eyeball Network IP Camera Security Protection

Be the first to leave a review.

122,99 €

Share

  • Brand Name: Dahua
  • Zoom type: None
  • Megapixels: 4MP
  • Zoom: None
  • Origin: Mainland China
  • High Definition: 4.0 Megapixels
  • Hign-concerned Chemical: None
  • Lens Quantity: Single Lens
  • Supported Operating Systems: Windows XP, Windows 7, Mac OS, Windows 8, Windows 10
  • TF Card: None
  • Lens (mm): 3.6mm, 2.8mm
  • Power Supply: With Poe
  • Style: Dome Camera
  • Connectivity: IP/Network Wired
  • Installation: Ceiling, Wall Mounted
  • Minimum Illumination(Lux): 0.004 Lux@F1.0
  • Scene: Indoor and outdoor
  • Color Night Vision: Yes
  • Internal Storage: 256GB
  • Video Compression Format: MJPEG, H.264, H.265
  • IR Distance(m): 30 m
  • Certification: CE, FCC, UL
  • Dimensions (L x W x D)(mm): 100.9 mm *109.9 mm
  • Color: WHITE
  • Power Mode: Mains Electricity
  • Alarm Action: FTP Photo, Email Photo, Local Alarm
  • Model Number: IPC-HDW2439T-AS-LED-S2
  • Supported Mobile Systems: Android, iOS
  • AI Functions: Motion Detection
  • IP Rating: IP67
  • Special Features: Waterproof / Weatherproof
  • App name: Imou Life
  • Power Supply(V): 12V DC/PoE (802.3af)
  • Audio Output: None
  • Power Consumption(W): <7.4 W
  • Sensor: CMOS
  • Shell Material: Metal
  • Viewing Angle : 96°
  • Audio: Built-in Mic

Original | Multi-Language,It could support upgraded at official website.

IPC-HDW2439T-AS-LED-S2

4MP Lite Full-color Fixed-focal Eyeball Network Camera

> 4MP, 1/3″ CMOS image sensor, low illuminance, high image definition

> Outputs 4MP (2560 × 1440) @ 25/30 fps, Max. supports 4MP (2688 × 1520) @ 20 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in warm lights, max. illumination distance: 30 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card and built-in Mic

> 12V DC/PoE power supply

> IP67 protection

Power

Power Supply

12V DC/PoE (802.3af)

Power Consumption

<7.4 W

Environment

Operating Conditions

–40 °C to +60 °C (–40 °F to +140 °F)/less than ≤ 95% RH

Storage Temperature

–40 °C to +60°C (–40 °F to +140 °F)

Protection Grade

IP67

Structure

Casing

Inner core: metal; cover: plastic ( pedestal: plastic )

Dimensions

100.9 mm × Φ109.9 mm (4.0″ × Φ4.3″)

Net Weight

0.365 kg (0.8 lb)

Gross Weight

0.527 kg (1.2 lb)

Camera

Image Sensor

1/3” 4Megapixel progressive CMOS

Max. Resolution

2688 (H) × 1520 (V)

ROM

128 MB

RAM

128 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Minimum Illumination

0.004 Lux@F1.0

S/N Ratio

>56 dB

Illumination Distance

30 m (98.4 ft)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (Warm light)

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–78°

Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm

3.6 mm

Max. Aperture

2.8 mm: F1.0

3.6 mm: F1.0

Field of View

2.8 mm: Horizontal 96° × Vertical 51° × Diagonal 115°

3.6 mm: Horizontal 81° × Vertical 44° × Diagonal 97°

Iris Type

Fixed

Close Focus Distance

2.8 mm: 1.3 m (4.3 ft)

3.6 mm: 1.8 m (5.9 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

56.0 m

(183.7 ft)

22.4 m

(73.5 ft)

11.2 m

(36.7 ft)

5.6 m

(17.1 ft)

3.6mm

72.0 m

(236.2 ft)

28.8 m

(94.5 ft)

14.4 m

(47.2 ft)

7.2 m

(23.6 ft)

Smart event

IVS

Tripwire; intrusion

Video

Video Compression

H.265; H.264; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.265+/ Smart H.264+

Video Frame Rate

Main stream:

2688 × 1520 (1 fps–20 fps)

2560 × 1440 (1 fps–25/30 fps)

Sub stream:

704 × 576 (1 fps–20/25 fps)

704 × 480 (1 fps–20/30 fps)

Stream Capability

2 streams

Resolution

2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps

Day/Night

Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 2688×1520 resolution and lower.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Built-in MIC

Yes

Audio Compression

G.711A; G.711Mu; G.726

Alarm

Alarm Event

No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; audio detection; safety exception

Network

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec

User/Host

20 (Total bandwidth: 72 M.)

Storage

FTP; Micro SD card (support max. 256 G); NAS; SFTP

Browser

IE

Chrome

Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――― ―――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――

About Product

     ⑴ . All Dahua products are produced by Dahua, guaranteed original, have been tested before leaving the factory, quality                           assurance,Please rest assured to use.

     ⑵ . The camera supports multiple languages, And the NVR supports all languages in the world.

      ⑶ . Dahua original series support upgrade and P2P, Android and IOS.

About Transport

      ⑴ . After you place an order, we will deliver the goods within 24 hours. When the stock is insufficient, it will  take 3 days to                         purchase. Some products need to be ordered. Dahua takes a month to produce.

      ⑵ .  All goods are shipped from China, usually most national standard shipping takes 7-60 days to deliver, Fast shipping takes 5-              15 days,

      ⑶ . If the goods are damaged due to transportation, please refuse to sign and keep the evidence, And contact us immediately.

About tax

      ⑴ . When the goods arrive at the local customs, the customs will decide whether to levy tax. Taxation is the obligation of citizens                of  each country. Please cooperate with customs and logistics service providers for customs clearance. If the package is not                processed for a long time, the package will be destroyed or returned, And the loss shall be borne by the buyer.

     ⑵ . The taxation of each country is different, Please contact the local customs for inquiries before purchasing.

 About After-sales

      ⑴ . If there is any question, please contact us first, We will give you a satisfactory answer instead of filing a dispute, Which                       cannot solve the problem better.

    ⑵ . If you find that the equipment has quality problems, Please contact us within 7 days from the date of receipt.

      ⑶ . If there is a quality problem within one year, we can repair it for free, And the buyer bears the cost of accessories and                           transportation.

Good Review

       If you are satisfied with our goods and services, please give a 5-Star praise after signing, So that we can provide better goods            and services. Great reviews we offer gifts and coupons, Please contact us before your next purchase.

――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――― ―――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――――
